Structures - Greenhouses

GOME greenhouses in the years have been for our customers, synonym of commitment to quality and maximum functionality: today may be the subject of energy conversation to renewable energy sources with high efficiency.

Greenhouse - MOD "SPRING TIME"



Request Information

Send
* denotes mandatory field





It’s a modular structure with two semispherical gables fully galvanized. It’s designed and built to meet the highest requirements of realiability as regards strength and durability.


  • Product description
  • Specifications

It’s a modular structure with two semispherical gables fully galvanized. It’s designed and built to meet the highest requirements of realiability as regards strength and durability. For these reasons it is mainly used to greenhouses plants of valuable crops due to high-tech plants.

As well as for cultivation greenhouses, it is used also for the realization of garden center and farm sheds.



Types of coverage

  • Glass

The glass panes model “gardener” or “polished” (possibly tempered) are supported by aluminium or galvanized steel glass-door . The thermal bridges are protected through DUTRAL or PDV seals

  • Double plastic film

Through the blowing of air between the two tarp by means of an electric blower, is generated the tension of the film itself and simultaneously it produces an effective insulation between the exterior and the interior of the greenhouse

  • Polycarbonate

Cover appropriate to reduce heat loss with a consequent energy saving. It’s available in various thickness, layers, shades and degrees of light diffusion

  • Corrugated plastic

Strenght and wear resistence are the main features of this coverage accompained by special anchoring systems and air adn water isolation seals



Aeration

  • Continuous doors with 1 or 2 cages

Arranged for the plugging with corrugated plastic

  • Side doors with 1 cage (about 1,50 mt.)

With “compasses” functioning

  • Side doors with 1 cage (about 1,00 mt.)

With “guillotine” functioning

  • Side openings bottom/top

Type of side or headboard  areation with winding of the plastic film  from the bottom to the top with the possibility of automation with electric motor. On demand it’s possible to create double openings from the bottom to the top in indipendent functioning

  • Side openings top/bottom

Particularly suitable for the areation in the upper part of the side panel, in order to avoid harmful flows for specific types of crops. Everything is automated by electric motor



Accessories

  • Side panels and interior divisions

Entirely infilled of corrugated plastic

  • Central interaxes editable

Entirely infilled of corrugated plastic, glass and polycarbonate

  • Plugging of headboards

Predisposition of the structure to the plastic film or to the corrugated plastic including sliding doors with one or two cages

  • Doors

The sliding doors with 1 or 2 cages can be realized in steel, hot dip galvanized or in aluminum. In the garden center are planned swing doors with panic bars or sliding automatically with photocell



  L (mt)  H palo (mt)  H colmo (mt)  P (mt)
Springtime mt 10   10,00
3,00/3,50/4,00  H+2,00  3,00/3,72/4,00
Springtime mt 11  11,00  3,00/3,50/4,00  H+2,20  3,00/3,72/4,00
Springtime mt 12  12,00  3,00/3,50/4,00 H+2,40  3,00/3,72/,400
Springtime mt 13  13,00  3,00/3,50/4,00  H+2,60  3,00/3,72/4,00
